P. 253

 VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF. GAS LIQUID
AC DC AC DC
300 200 300 200 270 120 120 65 135504030
70353020 55302515
ORDERING INFORMATION:
ORIFICE SIZE N.O.
1/32 3/64 1/16 5/64 3/32
LOW WATTAGE
CV FACTOR N.O.
.020 .048 .075 .134 .150
VALVE NUMBER
SLW51G8XCCP SLW51H8XCCP SLW51J8XCCP SLW51V8XCCP SLW51K8XCCP
.60 15.2
1/8-27 NPT OUTLET
3.06 77.8
.30 7.5
.59 15
1.50 38.1
1.20 30.5
1.00 25.3
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (SLW51J8XCCPL 120/60) REPAIR PACK (KSLW51J AC)
WHEN ORDERING OPERATORS ADD THE LETTER ā€œOā€ TO THE FRONT OF THE VALVE NUMBER,
REPLACE BODY PORT NUMBER WITH THE LETTER ā€œDā€: EXAMPLE: OPERATOR (OSLW51J8DCCPL 120/60)
2X 8-32 UNC-2B
.23 MFT
.20 5 .40 10.1
1/8-27 NPT INLET
.30 7.5
1/2-14 NPT CONDUIT
1.57 39.9
SERIES 50
SERIES 50 SLW
MODEL EW51
MODEL SLW51
2WNO
2WNO
EXPLOSION PROOF
