P. 285

 1/4 OR 1/8 NPT N.O.
3.60 91.4
1/4 OR 1/8 NPT N.C.
.88 22.3
1.22 30.9
1.78 45.1
1.61 41
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
DC
400 150 100 75
ORIFICE SIZE N.C. N.O.
CV FACTOR N.C. N.O.
DIN COIL
1/8 NPT PORTS
26GG7XELM 26HH7XELM 26JJ7XELM 26KK7XELM
VALVE NUMBER 1/4 NPT PORTS
26GG9ZELM 26HH9ZELM 26JJ9ZELM 26KK9ZELM
LEADED COIL
1/8 NPT PORTS
26GG7XGLM 26HH7XGLM 26JJ7XGLM 26KK7XGLM
1/4 NPT PORTS
26GG9ZGLM 26HH9ZGLM 26JJ9ZGLM 26KK9ZGLM
2X 10-32 UNF-2B
.88 22.3
(+) SPADE TO UNLATCH
1/4 OR 1/8 NPT COM
.31 MFT
(+) SPADE TO UNLATCH
(+) LEAD YELLOW TO LATCH
(+) LEAD BLUE
TO UNLATCH
SERIES 20
SERIES 20
SERIES 20 MODEL 26
SERIES 20 MODEL 26
MODEL 23
MODEL 23
3-WAY MULTI-PURPOSE
3-WAY MULTI-PURPOSE
3-WAY MULTI-PURPOSE
3-WAY MULTI-PURPOSE
MAGNETIC LATCHING DIN COIL
MAGNETIC LATCHING COIL WITH LEADS
DIN COIL MAGNETIC LATCHING
COIL WITH LEADS MAGNETIC LATCHING
1/32 1/32 .024 .024 3/64 3/64 .052 .052 1/16 1/16 .095 .095 3/32 3/32 .156 .156
ORDERING INFORMATION:
WHEN ORDERING VALVES OR REPAIR PACKS ADD VALVE NUMBER. EXAMPLES: VALVE (26JJ7XELM
VOLTAGE AND FREQUENCY TO COMPLETE 12/DC) REPAIR PACK (K26JJXL DC)
WHEN ORDERING OPERATORS ADD THE LETTER ā€œOā€ TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER ā€œDā€: EXAMPLE: OPERATOR (O26JJ7DELM 12/DC)
1.86 47.2
.34 8.8
