3.51 89.2
1/4 OR 1/8 NPT EXH
.88 22.3
.44 11.1
1/2-14 NPT CONDUIT
1/4 OR 1/8 NPT CYL
.31 MFT
.44 11.1
.88 22.3
1.75 44.4
.34 8.8
1/4 OR 1/8 NPT IN
1.55 39.4
1.63 41.4
1.61 41
.86 21.8
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
DC
1000*
ORIFICE SIZE N.O. N.C.
0.6 mm 1/32
CV FACTOR N.O. N.C.
.010 .022
VALVE NUMBER 1/8 NPT PORTS 1/4 NPT PORTS
H24MG7XGM H24MG9ZGM
CONDUIT HOUSING 1/8 NPT PORTS
H24MG7XCM
2X 10-32 UNF-2B
SERIES 20
SERIES 20
MODEL H24
MODEL H24
SERIES 20 MODEL H24
SERIES 20 MODEL H24
3WNO
3WNO
3-WAY NORMALLY OPEN
3-WAY NORMALLY OPEN
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
CONDUIT COIL CONNECTION
GROMMET HOUSING WITH LEADS
* FKM seals not recommended for pressure above 500 psi.
ORDERING INFORMATION:
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (H24MG7XGM 120/60) REPAIR PACK (KH24MGX AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (OH24MG7DGM 120/60)
GROMMET HOUSING
1/4 NPT PORTS
H24MG9ZCM
