VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
DC GAS ONLY
120
ORIFICE SIZE N.C. N.O.
1/32 1/32
CV FACTOR N.C. N.O.
.022 .020
VALVE NUMBER
SLLW53GG8DCCP
ORDERING INFORMATION:
.60 15.2
2.43 61.8
1/8-27 NPT INLET
.59 15
1.50 38.1
.23 MFT
1.20 30.5
EXHAUST
2X 8-32 UNC-2B
25.3
.40 10.1
SERIES 50 SLLW MODEL SLLW53
3WNC EXHALOUWST WTOATATTAMGOE SPHERE EXPLOSION PROOF
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (SLLW53GGDCCP 12/DC) REPAIR PACK (KSLLW53GGD DC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER,
REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (OSLLW53GGDCCP 12/DC)
1/8-27 NPT CYL
1/2-14 NPT CONDUIT
1.57 39.9
2X .30
7.5 1.00
SERIES 50
3WNC EXMHOADUESTL ETWO5A3TMOSPHERE
