1/4 OR 1/8 NPT IN
3.60 91.4
1/4 OR 1/8 NPT EXH
.44 11.1
.88 22.3
1.22 30.9
1.78 45.1
1.61 41
.91 23.2
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
DC
400
150
100
100
100
75
ORIFICE SIZE
CV FACTOR
DIN COIL
1/8 NPT PORTS
24GG7XELM 24HJ7XELM 24JJ7XELM 24JK7XELM 24JN7XELM 24KN7XELM
VALVE NUMBER 1/4 NPT PORTS
24GG9ZELM 24HJ9ZELM 24JJ9ZELM 24JK9ZELM 24JN9ZELM 24KN9ZELM
LEADED COIL
1/8 NPT PORTS
24GG7XGLM 24HJ7XGLM 24JJ7XGLM 24JK7XGLM 24JN7XGLM 24KN7XGLM
ORDERING INFORMATION:
2X 10-32 UNF-2B
.88 22.3
N.O.
1/32 3/64 1/16 1/16 1/16 3/32
N.C. N.O.
1/32 .024 1/16 .052 1/16 .095 3/32 .095
1/8 .095 1/8 .156
N.C.
.024 .095 .095 .156 .214 .214
1/4 NPT PORTS
24GG9ZGLM 24HJ9ZGLM 24JJ9ZGLM 24JK9ZGLM 24JNZZGLM 24KN9ZGLM
WHEN ORDERING VALVES OR REPAIR PACKS ADD VALVE NUMBER. EXAMPLES: VALVE (24JJ7XELM
VOLTAGE AND FREQUENCY TO COMPLETE 12/DC) REPAIR PACK (K24JJXL DC)
(+) SPADE TO LATCH
DIN FORM 43650 MATING CONNECTOR PPE #20-198
1/4 OR 1/8 NPT CYL
.31 MFT
.44 11.1
(+) TO
1.86 47.2
.34 8.8
SPADE UNLATCH
(+) LEAD YELLOW TO LATCH
SERIES 20
SERIES 20
SERIES 20 MODEL 24
SERIES 20 MODEL 24
MODEL 23
MODEL 23
3-WAY NORMALLY OPEN
3-WAY NORMALLY OPEN
3WNO
3WNO
MAGENTIC LATCHING DIN COIL
MAGENTIC LATCHING COIL WITH LEADS
DIN COIL MAGNETIC LATCHING
COIL WITH LEADS MAGNETIC LATCHING
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O24JJ7DELM 12/DC)
