FILTERS AND MUFFLERS
.13 DIA WRENCH HOLE
(2) Places
1/8 NPT PIPE PORTS-BOTH SIDES
1.08
FILTER
HOUSING
.38
(2) Places
FILTER/STRAINER
The Peter Paul Filter Strainers are designed for the customer who needs efficient filtration of large contaminating particles along with ease of servicing. The 43 Micron screen has a large filter area and can be cleaned without removing the filter body from the system.
SPECIFICATIONS:
1.00 DIA
1.19 DIA
FLANGE CAP
1.38
Pipe Size: 1/8 NPT CV=.23
1.86 Screen Rating: 43 Micron or 140 Micron
Max. Working Press. Diff.: 300 PSI
Burst Press.: 4000 PSI
Temp.: -40° to +200°F
Materials: Brass Body and Filter Hsg.,Stainless Strainer and Flange Cap Buna N Seals
Media: All non-corrosive liquids & gases INLINE FILTER
The Peter Paul Inline Filters are designed to be a convenient “last chance” filter which provides maximum protection for all fluid power devices. Female/Male pipe threads are provided for ease of installation. Available in four micron ratings.
SPECIFICATIONS:
Pipe Size: 1/8 or 1/4 NPT
Micron Rating: 20,40, 60, or 100
Max. Working Press. Diff.: 300 PSI
Element Burst Press. Diff.: 1500 PSI
Temp.: -40° to +300°F
Materials: Brass Body with sintered Bronze Filter Element Media: All non-corrosive liquids & gases
EXHAUST MUFFLER
The Peter Paul Exhaust Muffler is designed for use with air cylinders and control valves or wherever excessive noise due to exhausting air is a problem. These mufflers will fit into any 1/8 or 1/4 pipe port and will reduce exhaust noise substantially, yet will not cause excessive restriction.
SPECIFICATIONS:
Pipe Size: 1/8 or 1/4 NPT
Max. Working Press. Diff.: 400 PSI
Element Burst Press. Diff.: 4000 PSI
Temp.: -40° to +300°F
Materials: Stainless Steel Body with Sintered Stainless Element (75 Micron) Media: Air and most gases
1.25 DIA. MAX
