Page 99 - Peter Paul 2019 Catalog

EXHAUST
3.50 88.8
.44 11.1
.88 22.3
47.9
1/4-18 NPT IN
2X 10-32 UNF-2B
.31 MFT
.44 11.1 .88 22.3
2.25 1.88 57.2
1.18 29.9
SERIES 70
SERIES 70
SERIES 70
SERIES 70
MODEL 73 1/4-18 NPT
MODEL 73 1/4-18 NPT
MODEL 73 1/4-18 NPT
MODEL 73 1/4-18 NPT
3WNC EXHAUST TO ATMOSHPERE
3WNC EXHAUST TO ATMOSHPERE
3WNC EXHAUST TO ATMOSPHERE
3WNC EXHAUST TO ATMOSPHERE
VALVE SPECIFICATIONS
MAX. OPER.
PRESS. DIFF. ORIFICE SIZE
AC DC N.C. N.O.
CV FACTOR N.C. N.O.
.09 .09 .22 .22 .35 .35 .45 .45 .50 .50 .78 .50
VALVE NUMBER
350 350
250 250
175 175
125 125
100 100
50 50
1/16 1/16 3/32 3/32 1/8 1/8 5/32 5/32 3/16 3/16
1/4 3/16
GROMMET HOUSING 1/4 NPT PORTS
73JJ9DGM 73KK9DGM 73NN9DGM 73OO9DGM 73PP9DGM 73RP9DGM
CONDUIT HOUSING 1/4 NPT PORTS
73JJ9DCM 73KK9DCM 73NN9DCM 73OO9DCM 73PP9DCM 73RP9DCM
ORDERING INFORMATION:
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
2.48 63
2X .35 1.61 8.8 41
1/2-14 NPT CONDUIT
1/4-18 NPT CYL
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (73OO9DGM 120/60) REPAIR PACK (K73OOD AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O73OO9DGM 120/60)
