Page 19 - Peter Paul 2019 Catalog

1.29 32.8
1.16 29.4
1.13 28.6
2X 8-32 UNC-2B
.20 5 .40 10.1
.68 17.3
LEAD WIRES
1/2-14 NPT CONDUIT
1.61 41
2.51 63.8
OUT
.30 7.5
DIN FORM 43650
1/8-27 NPT
INLET .88
22.2 .23 MFT
2X .30 7.5
.59 15
SERSEIERISES115
SERIES 15
SERIES 15
MODEL 152
SERIES 15 MOMDOEDLE15L2152
SERIES 15 MODMEOLD1E5L2152
MODEL 152
2-WAY NORMALLY CLOSED
CONDUIT2CWONILCONNECTION 2WNC 2WNC
CONDUIT CONNECTION
VALVE SPECIFICATIONS
2-WAY NORMALLY CLOSED DIN STYLE COIL
LEAD WIRE
152G2DGM 152H2DGM 152J2DGM 152K2DGM
2-WAY NORMALLY CLOSED MOLDED COIL WITH LEADS
DIN STYLE
MOLDED WITH LEADS
MAX. OPER. PRESS. DIFF.
AC DC
500 500 400 400 200 200 150 100
ORIFICE SIZE N.C.
1/32 3/64 1/16 3/32
CV FACTOR N.C.
.022 .055 .075 .130
VALVE NUMBER DIN STYLE
152G2DEM 152H2DEM 152J2DEM 152K2DEM
CONDUIT HOUSING
152G2DCM 152H2DCM 152J2DCM 152K2DCM
ORDERING INFORMATION:
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (152J2DGM 120/60) REPAIR PACK (K152JD AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O152JDDGM 120/60)
