P. 207

 1/4-18 NPT OUTLET
3.81 96.8
.44 11.1
.88 22.3
1.88 47.9
2.25 57.2
1.44 36.5
3.44 87.3 2.75 69.9
2X 10-32 UNF-2B
.31 MFT
.44 11.1
.88 22.3
.35 1.61 8.8 41
VALVE SPECIFICATIONS
MAX. OPER.
PRESS. DIFF. ORIFICE SIZE
AC DC N.O.
CV FACTOR N.O.
.09 .22 .35 .45 .50
VALVE NUMBER CONDUIT HOUSING
1/4 NPT PORTS
N71J9ZCP N71K9ZCP N71N9ZCP N71O9ZCP N71P9ZCP
350     350
250     250
175     175
125     125
100     100
1/16 3/32 1/8 5/32 3/16
ORDERING INFORMATION:
SERIES N70 MODEL N71 1/4-18 NPT
SERIES N70 MODEL N71 1/4-18 NPT
SERIES 70
SERIES 70
2WNO
2WNO
MODEL N71 1/4-18 NPT CONDUIT2CWONONECTION CONDUIT CONNECTION
MODEL N71 1/4-18 NPT CONDUIT W2ITWHNBORACKET
2.48 63
2.44 61.9
.27 6.8
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (N71P9ZCP 120/60) REPAIR PACK (KN71PDX AC)
WHEN ORDERING OPERATORS ADD THE LETTER ā€œOā€ TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER ā€œDā€: EXAMPLE: OPERATOR (ON71P9DCP 120/60)
1/2-14 NPT CONDUIT
1/4-18 NPT INLET
.20 5.2
CONDUIT WITH BRACKET
