1/8-27 NPT OUTLET
2.96 75.2
.59 15
.30 7.5
1.38 35.1
1.05 26.7
1.00 25.3
.71 18
2X 8-32 UNC-2B
.23 MFT
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF. GAS LIQUID
AC DC AC DC
300 200 300 200 270 120 120 65 135504030
70353020 55302515
ORDERING INFORMATION:
ORIFICE SIZE N.O.
1/32 3/64 1/16 5/64 3/32
CV FACTOR N.O.
.020 .048 .075 .134 .156
VALVE NUMBER
.20 5 .40 10.1
1/8-27 NPT INLET
.30 7.5
1/2-14 NPT CONDUIT
1.50 38
SERIES 50 MODEL LW51
SERIES 50 LW MODEL LW51
LW MODEL LW51
MODEL LW51
2WNO
2WNO
2WNO
2WNO
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (LW51J8XGML 120/60) REPAIR PACK (KLW51JX AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (OLW51J8DGML 120/60)
GROMMET 1/8 NPT
LW51G8XGM LW51H8XGM LW51J8XGM LW51V8XGM LW51K8XGM
CONDUIT 1/8 NPT
LW51G8XCM LW51H8XCM LW51J8XCM LW51V8XCM LW51K8XCM
