600* 200 250 80 150 50 100 25
600* 200 250 80 150 50 100 25
1/32 3/64 1/16 5/64 3/32 1/8 5/32
GROMMET 1/8 NPT
LW52G8DGM LW52H8DGM LW52J8DGM LW52V8DGM LW52K8DGM LW52N8DGM LW52O8DGM
CONDUIT 1/8 NPT
LW52G8DCM LW52H8DCM LW52J8DCM LW52V8DCM LW52K8DCM LW52N8DCM LW52O8DCM
1.05 26.7
1/8-27 NPT OUTLET
.59 15
1.38 35.1
2X 8-32 UNC-2B
.71 18
85 20 85 20 50 50
15 15
2.38 60.5
1/2-14 NPT CONDUIT
1.50 38
.30 .20 7.5 5
.40 10.1
SERIES 50
SERIES 50
MODEL LW52
MODEL LW52
* FKM seals not recommended for pressure above 500 psi.
ORDERING INFORMATION:
SERIES 50 LW
SERIES 50 LW
2WNC
2WNC
MODEL LW52
MODEL LW52
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
VALVE NUMBER
2WNC CONDUIT CONNECTION
2WNC
GROMMET HOUSING WITH LEADS
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
GAS LIQUID ORIFICE
ACDCACDCN.C.
SIZE
CV FACTOR N.C.
.022 .055 .075 .134 .156 .230 .292
.23 MFT
1/8-27 NPT INLET
.30 7.5
1.00 25.3
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (LW52J8DGML 120/60) REPAIR PACK (KLW52J AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (OLW52J8DGML 120/60)
