Page 243 - Peter Paul 2019 Catalog

1.05 26.7
1/8-27 NPT INLET
.59 15
.30 7.5
1.05 26.7
1.38 EXHAUST 35.1
2.39 60.8
.71 18
7.5 1.00 2X 8-32 UNC-2B .23 MFT 25.3
SERIES 50 LW MODEL LW52
SERIES 50 LW MODEL LW52
3WNC EXHAUST TO ATMOSPHERE
3WNC EXHAUST TO ATMOSPHERE
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
3WNC EXHAUST TO ATMOSPHERE CONDUIT CONNECTION
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
GAS LIQUID ORIFICE SIZE
ACDCACDCN.C. N.O.
3WNC EXHAUST TO ATMOSPHERE GROMMET HOUSING WITH LEADS
215 135 215 120 135 50 70 35 55 30 120 70 120 50 70 35 55 30 85 40 70 35 55 30 50 30 50 30 35 20
215 135 120 65 40 30 30 20 25 15 120 65 40 30 30 20 25 15 40 30 30 20 25 15 30 20 25 15 25 15
1/32 1/32 1/32 3/64 1/32 1/16 1/32 5/64 1/32 3/32 3/64 3/64 3/64 1/16 3/64 5/64 3/64 3/32 1/16 1/16 1/16 5/64 1/16 3/32 5/64 5/64 5/64 3/32 3/32 3/32
CV FACTOR N.C. N.O.
.022 .022 .022 .048 .022 .075 .022 .134 .022 .156 .055 .048 .055 .075 .055 .134 .055 .156 .075 .075 .075 .134 .075 .156 .134 .134 .134 .156 .150 .156
VALVE NUMBER GROMMET 1/8 NPT
LW53GG8DGM LW53GH8DGM LW53GJ8DGM LW53GV8DGM LW53GK8DGM LW53HH8DGM LW53HJ8DGM LW53HV8DGM LW53HK8DGM LW53JJ8DGM LW53JV8DGM LW53JK8DGM LW53VV8DGM LW53VK8DGM LW53KK8DGM
CONDUIT 1/8 NPT
LW53GG8DCM LW53GH8DCM LW53GJ8DCM LW53GV8DCM LW53GK8DCM LW53HH8DCM LW53HJ8DCM LW53HV8DCM LW53HK8DCM LW53JJ8DCM LW53JV8DCM LW53JK8DCM LW53VV8DCM LW53VK8DCM LW53KK8DCM
ORDERING INFORMATION:
.20 5 .40 10.1
SERIES 50
SERIES 50
MODEL LW53
MODEL LW53
1/8-27 NPT CYL
.30
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (LW53JJ8DGML 120/60) REPAIR PACK (KLW53JJD AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER,
REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (OLW53JJ8DGML 120/60)
1/2-14 NPT CONDUIT
