 1/8-27 NPT 1.57 EXHAUST 39.8
INLET CYL
2.12 1/8-27 NPT 53.9
1.33 33.7
2.75 69.9
1.73 44
2X .66 16.9
.49 12.4
2X .078 .19
(#2 PLASTITE SCREWS)
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
AC
150 60 30
WITHOUT BRACKET
43JJ15XGM 43KK15XGM 43NK15XGM
WITH BRACKET
43JJ15XBGM 43KK15XBGM 43NK15XBGM
1.33 2X 1/8-27 NPT 33.7
.49 12.4
2X .078 .19
(#2 PLASTITE SCREWS)
CYL
SERIES 40
SERIES 40
SERIES 40
SERIES 40
MODEL 43 (NO BRACKET)
MODEL 43 (WITH BRACKET)
MODEL 43 (NO BRACKET)
MODEL 43 (WITH BRACKET)
3WNC PIPED EXHAUST
3WNC PIPED EXHAUST
3WNC PIPED EXHAUST
3WNC PIPED EXHAUST
MOLDED WITH LEADS
MOLDED WITH LEADS
MOLDED WITH LEADS
MOLDED WITH LEADS
ORIFICE SIZE DC N.C. N.O.
150 1/16 1/16 60 3/32 3/32 30 1/8 3/32
CV FACTOR N.C. N.O.
.090 .075 .145 .145 .200 .145
VALVE NUMBER
ORDERING INFORMATION:
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (43JJ15XGM 120/60) REPAIR PACK (K43JJX AC)
NO OPERATOR AVAILABLE
2.78 70.5
2X .35 8.8
.27
6.8 R.10 2.6
1.24 31.5
INLET
2X .66 16.9
.63 15.9
2.78 70.5
2X .35 8.8
EXHAUST
.95 24.1
