Page 67 - Peter Paul 2019 Catalog

1/8-27 NPT OUTLET
2.96 75.2
.59 15
.30 7.5
1.38 35.1
1.05 26.7
1.00 25.3
.71 18
2X 8-32 UNC-2B
.23 MFT
.20 5 .40 10.1
VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
AC DC
400 200 200 100 125 60 40 40
ORIFICE SIZE N.O.
1/32 3/64 1/16 3/32
CV FACTOR N.O.
.020 .048 .075 .150
GROMMET HOUSING 1/8 NPT PORTS
51G8XGM 51H8XGM 51J8XGM 51K8XGM
CONDUIT HOUSING 1/8 NPT PORTS
51G8XCM 51H8XCM 51J8XCM 51K8XCM
ORDERING INFORMATION:
1/8-27 NPT INLET
.30 7.5
1/2-14 NPT CONDUIT
1.50 38
SERIES 50
SERIES 50
SERIES 50
SERIES 50
MODEL 51
MODEL 51
MODEL 51
MODEL 51
2WNO
2WNO
GROMMET HOUSING WITH LEADS
VALVE NUMBER
2WNO
2WNO
GROMMET HOUSING WITH LEADS
CONDUIT CONNECTION
CONDUIT CONNECTION
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (51J8XGM 120/60) REPAIR PACK (K51JDX AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O51J8DGM 120/60)
