Page 79 - Peter Paul 2019 Catalog

1/8-27 NPT N.C.
.59 15
.30 7.5
1/8-27 NPT COM
2X .30 7.5
1.00 25.3
1.38 1/8-27 NPT 35.1
2.96 75.2
2X 8-32 UNC-2B .23 MFT
.20 5 .40 10.1
.71 18
VALVE SPECIFICATIONS
MAX. OPER.
PRESS. DIFF. ORIFICE SIZE
AC DC N.C. N.O.
125 125 1/32 1/32 100 100 3/64 3/64 65 50 1/16 1/16 25 25 3/32 3/32
ORDERING INFORMATION:
CV FACTOR N.C. N.O.
VALVE NUMBER
N.O.
SERIES 50
SERIES 50
SERIES 50
SERIES 50
MODEL 56
MODEL 56
MODEL 56
MODEL 56
3-WAY MULTI-PURPOSE
3-WAY MULTI-PURPOSE
3W MULTI-PUPOSE
3W MULTI-PUPOSE
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
.022 .020 56GG8XGM .055 .048 56HH8XGM .075 .075 56JJ8XGM .156 .150 56KK8XGM
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (56JJ8XGM 120/60) REPAIR PACK (K56JDX AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O56JJ8DGM 120/60)
1/2-14 NPT CONDUIT
GROMMET HOUSING 1/8 NPT PORTS
CONDUIT HOUSING 1/8 NPT PORTS
56GG8XCM 56HH8XCM 56JJ8XCM 56KK8XCM
